Growatt 5Kw Solar Inverter SPF 5000 ES
Growatt 5Kw Solar Inverter SPF 5000 ES - Image 2
Growatt 5Kw Solar Inverter SPF 5000 ES - Image 3
Rural Sun Power > Products > Growatt 5Kw Solar Inverter SPF 5000 ES

Growatt 5Kw Solar Inverter SPF 5000 ES

Original price was: 85,000.00৳ .Current price is: 75,000.00৳ .

Category:
Item Dimensions LxWxH 19.09 x 12.99 x 5.31 inches
Input Voltage 48 Volts
Output Power 5000 Watts
Warranty 2 years

Description

Model ✅ Growatt SPF 5000 ES
  • Integrated MPPT Charge Controller: Yes
  • Equalization Charging Function: Yes
  • Work with or Without Battery: Yes
  • PV input voltage up to 450VDC: Yes
  • Configurable Grid or Solar Input Priority: Yes
  • WIF / GPRS Remote Monitoring: Yes
  • Battery Voltage: 48V DC
  • Battery Type: 5000VA/5000W
  • Inverter Output
    • Rated Power: 5000VA/5000W
    • Parallel Capability: Yes, 6 units Maximum
    • AC Voltage Regulation(Battery Mode): 230VAC+- 5% @ 50/60Hz
    • Surge Power: 10000VA
    • Efficiency (Peak): 93%
    • Waveform: Pure sine wave
    • Transfer Time: 10ms typical, 20ms MAx
  • Solar Charger
    • Maximum PV Array Power: 6000W
    • MPPT Range at Operating Voltage: 120VDC-430VDC
    • Number of Independent MPP Trackers/Strings per MPP Tracker: 1/1
    • Maximum PV Array Open Circuit Voltage: 450V DC
    • Maximum Solar Charger Current: 100A
  • AC Charger
    • Charger Current: 80A
    • AC Input Volatge:230VAC
    • Selectable Voltage Range:
    • 170-280 VAC for Personal Computers
    • 90-280VAC for Home Appliances
    • Frequency Range: 50/60Hz ( Auto Sensing)
  • Operating Environment
    • Altitude: up to 2000 m
    • Humidity: 5 to 95% relative humidity (non-condensing)
    • Operating Temperature: 0°C-55°C
    • Storage Temperature: -15°C -60°C
  • Physical
    • Protection Degree: IP20
    • Dimension (W x H x D): 300 x 485 x 134mm
    • Net Weight: 12 Kg

Description

Growatt SPF 5000 ES is a Hybrid Solar Inverter with a capacity of 5kW. It is a versatile off-grid solar inverter that comes with an MPPT solar charge controller, a high-frequency pure sine wave inverter, and a UPS function module in one machine. It is ideal for use in self-consumption and off-grid backup power. It can operate with a maximum PV input voltage of up to 450VDC and without a battery. This solar inverter can support power expansion up to 30kW.
